Air source High temperature average heating input power18.2KW Max outlet water temp80℃

Technology Specification Porduct Details

1 . MODEL MD300D 2 . Rated heating capacity 88KW

3 . Rated Cooling capacity 65KW 4 . Hot water supply 2400L / h

5 . Average heating input power 25KW 6 . Rated heating input current 45A

7 . Rate outlet water temp 80℃ 8 . COP 4.5

9 . Refrigerant R417A 10 . Noise 68Db ( a )

11 . Air source heat exchanger Finned heat exchange 12 . Power 380V/ 50HZ

13 . Dimension 2040 ×1100 ×2000MM 14 . Packing size 2080 * 1150 * 2310MM

15 . Unit weight 650KG 16 . Working air temp range (-20℃)—45

17 . compressor Copeland 18 . use porjct , dry room , hotel hot water

19 .Fan Type axial flow fan

20 . Hot water side heat exchange

( 1 ) water folw 30000L / H

( 2 ) water pressure down 60Kpa

( 3 )pipe size 50Db

( 4 )Max spuare mater 730M ²

Packaging Details
Carton and Wooden Package,
Delivery Time
15 working days after arrival of down payment

Welcome To Guangzhou Jin Lun Electric Equipment Co.,Ltd

19 Years Professional Heat Pump Manufacturer!

  Established in 2001 by Dr. Hong QinHui,Guangzhou Jin Lun Electric EquipmentCo.,Ltd is a technical developing & products manufacturer which have developed over dozen of series of products. The products include air source heat pump, ground source heat pump, constant temperature and dehumidification pool heat pump, water source heat pump, geothermal heat pump, ice storage air conditioner, and waste water energy recycled heat pump etc. Tilll now our company has owned 85 common product patents and 5 inventors patents and 1 international inventors' patent and some other patents technology Also we have been awarded with a ot of titles, such as National High-Tech Company, Private Science & Technology Company in Guang-zhou and Contracts Good Commitment Company in GuangDong Province.

In order to meet the need of our global development strategy, in the year of 2008, Meeting(R) heatpump company has constructed a garden style industrial center with 20000 square meter. Our factory now has equiped with a set of modernized All-Weathered Environmental simulator for experiment and a CNC module developed centre, a module injecting machine & etc. All these advanced equipment have greatly lift up the speed in transforming a diagram into a real product. As for our factory has been nominated as an experimental bases for a lo of academics and institutes, we have to carry out more social responsibilities than before.
