Meeting No noise heat pumps water heater household heat pump
cooling heating and hot water
Technology Specification
FEATURE
- with Advanced inverter technology, it saves 40% energy than
normal heat pump in practical operation.
- 5 modes to manage heating, cooling and DHW, fits your need all
year round.
- with temperature compensation function, the water setting
temperature adjusts automatically as the house's heat loss changes.
- Automatically variable fan speed in 3 grades to optimized heating
efficiency.
- Can work with room thermostat.
- Can work with auxiliary heater.
- Split design with water system indoor, preventing water frozen
problem.
- Aviation plug for wire connection between indoor unit and outdoor
unit, simplifies installation and avoids mistakes.
- with controller interface, plate heat exchanger, circulation
pump, flow switch, water pressure gauge in indoor unit.
- Allows absence of buffer tank.
A. Payment service
1. T/T
2. L/C (for container order only)
B. Technical service
1. We calculate the capacity and recommend the best models.
2.We supply you the professional refrigeration technical support
and electronic technical support for your installation, debugging
and operation.
3. We supply the spare parts and technical support in and after the
warranty time.
4. We supply the training course to your workers at our factory if
you need.
5. We can offer site training to your workers in your place which
is negotiable.
C. After-sales service
1. Technical support for your installation, operation and
maintenance
2. Standard warranty time: One years’warranty for heat pumps
You can also pay for extended warranty or we can renegotiate the
longer warranty period.
3. Spare parts and technical support at most economic prices after
the warranty.
FAQ
Why us?
1. Timely Delivery, considerate sales after service
2. Many Years quality warranty,OEM service.
3. Top Craftmanship, All products 100% tested
4. Preferential freight by Famous shipping company
5. New Design,Very popular style products recommendation for your
local market
Certificsate we have got :
- ISO 9001, ISO 14000
- Our company has been inspected and certificate by EMC
- CE And EN14511, EN 14825-ERP for heat pump exported to europe
- Energy label for all heat pump models sold to oversea market
- Testing laboratory calibrated by CNAS
Parameters table
| Rated heating capacity | KW | 18 |
| Hot water supply | L/h | 400 |
| Average heating input power | KW | 4.4 |
| Rated heating input current | A | 9 |
| Max outlet water temp | ℃ | 60 |
| COP | | 4.2 |
| Power | V/Hz | 380V/50 |
| Noise | Db(a) | 48 |
| Dimension | W*D*H | mm | 1200*700*1360 |
| packing size | W*D*H | mm | 1280*780*1420 |
| Unit weight | KG | 200 |
| Refrigerant | | R417A/R407C/R404A |
| Working air temp range | | (-25℃)—45℃ |
| compressor | Type | | Copeland |
| Air source heat exchanger | Type | | Finned heat exchange |
| Fan Type | | Centrifugal fan |
| Hot water side heat exchange | Type | | Coil heat exchanger |
| Water flow | M6/H | 5000L/h |
| Water pressure down | Kpa | 45 |
| Pipe size | DN | 25 |
compressor
The world-famous Copeland Flexible Scroll Compressor has functions
such as low wear resistance, long service life, over-current
protection, phase loss protection, over-the-counter protection,
strong liquid-impact resistance, and high and low voltage
protection. Copeland compressor built-in pressure relief valve in
the body can automatically relieve pressure when the high pressure
is too high
Electronic control system
With powerful engineering supporting control functions , it can
control circulating water pump, make-up water , return water, water
supply , electric heating , PID automatic defrosting, etc., making
the control easier. According to the needs of different projects,
it can set various parameters by itself and realize various water
supply schemes . The entire system can be automated without special
care.
Electronic expansion valve
The introduction of the latest Japanese technology in conjunction
with the company's control system has led to the development of a
unique electronic expansion valve control method and the use of
digital technology control to control the working fluid to achieve
the best flow velocity effect, thereby increasing the COP value.
