5HP Air Source Heat Pump 18KW heating Woking temperature -20--45
degree
Technology Specification
Air source heat pump water heater is one of the most economical
systems to heat water for family domestic use and commercial use.
Using free renewable energy from the air, the heat pump is highly
efficient with low cost. It can save energy up to 80% compared with
traditional gas boiler or electric water heater.
Features&Benefits
Easy installation with different water tanks
High efficiency with good performance
Famous brand compressor with R410a
Enlarged heat exchangers, high COP
Whisper quiet fan
Intelligent controller
Reverse cycle defrost with 4-way valve
Hydrophilic fin coil coating
Operation protection included
100% factory tested
MD50D air source heat pump parameters tables
| MODEL | Unit | MD50D |
| Rated heating capacity | KW | 18 |
| Rated Cooling capacity | | 12 |
| Hot water supply | L/h | 400 |
| Average heating input power | KW | 4.4 |
| Rated heating input current | A | 9 |
| Max outlet water temp | C | 60 |
| COP | | 4.2 |
| Power | V/Hz | 380V/50 |
| Noise | Db(a) | 55 |
| Dimension | W*D*H | mm | 1120*490*1270 |
| Packing size | W*D*H | mm | 1200*520*1425 |
| Unit weight | KG | 160 |
| Refrigerant | | R417A/R407C/R404A |
| Working air temp range | | (-20℃)—45℃ |
| compressor | Type | | Copeland |
| Air source heat exchanger | Type | | Finned heat exchange |
| Fan Type | | axial flow fan |
| Hot water side heat exchange | Type | | Coil heat exchanger |
| Water flow | L/H | 5000L/h |
| Water pressure down | Kpa | 45 |
| Pipe size | DN | 25 |
| Max flat spuare meter | M2 | 150 |
A. Payment service
1. T/T
2. L/C (for container order only)
B. Technical service
1. We calculate the capacity and recommend the best models.
2.We supply you the professional refrigeration technical support
and electronic technical support for your installation, debugging
and operation.
3. We supply the spare parts and technical support in and after the
warranty time.
4. We supply the training course to your workers at our factory if
you need.
5. We can offer site training to your workers in your place which
is negotiable.
C. After-sales service
1. Technical support for your installation, operation and maintenance.
2. Standard warranty time: One years’warranty for heat pumps
You can also pay for extended warranty or we can renegotiate the
longer warranty period.
3. Spare parts and technical support at most economic prices after
the warranty.
FAQ
Why us?
1. Timely Delivery, considerate sales after service
2. Many Years quality warranty,OEM service.
3. Top Craftmanship, All products 100% tested
4. Preferential freight by Famous shipping company
5. New Design,Very popular style products recommendation for your
local market
Packaging & Shipment
1>Meeting heat pump can sure delivery heat pump within 5~20
working days as we warehouse stock condition.
2>Heat pump with strong plywood pallet , strong plywood box for
loading, make sure no problem happen during rude transporattion .
3>All spare parts of the heat pump water heater will together
loading into package , one time finished shipment to buyer.
4>Take video of the heat pump for buyer before package to 100%
sure buyer get product same as order, no any different.
5>Meeting heat pump offer 100% test online, 5% test in Lab by 24
hour for one lot order (if not new model)
Packaging Details :Standard export packing -with plywoods case
packages,OEM is available for Factory price heat pump water heaters
Delivery Time :15 work days after arrival of down payment
ABOUT US
1). We were established in 2001.
2). We are a professional heat pump manufacturer, Located around
Baiyun Air port
3). We are trading on Meeting Brand ,Meeting heat pump Well-know
brand we operate in Europe market
4). Our company has been inspected and certificated by TUV and SGS.
5). We are the one of the first manufacturers whose heat pumps are
with top COP gaining grants from Chinese government.
6). We passed ISO 9001 quality management system and ISO14000
environment protection system
7). Our testing laboratory can test heat pump up to 60KW heating
capacity and create testing air temperature condition during
-25DegC~45DegC,according to EN14511 standard.
8). Our leading products: Air to water heat pump , DC inverter heat
pump, High water temperature heat pumps
Product packing, plywooden case
