18KW Residential Air Source Sanitary Hot Water Heat and Heating
Air source heat pump Technology Specification
Application
- air source heat pump (for house heating and cooling) is designed
for house heating and cooling, user can change the working mode by
operating wired panel of controller. Compressor start / stop
according to air conditioning system water temperature, when all
rooms reach preset temperature by room thermostat, heat pump will
be turned off through remote ON / OFF switch.
Advantages:
1.Generally cost less to operate than other types of conventional
heating systems, save your electricity or gas bills.
2.Operate at a high efficiency with no flames, fumes, or flues;
Water and electricity isolated.
3.With intelligent control systems which convenient and simple
operation
4.Provide hot water no matter in cloudy day, snowy day or at night,
unlike solar collectors which have to be facing the sun.
5.Transfer heat that’s already in the environment; Low CO2
emissions.
A. Payment service
1. T/T
2. L/C (for container order only)
B. Technical service
1. We calculate the capacity and recommend the best models.
2. We supply you the professional refrigeration technical support
and electronic technical support for your installation, debugging
and operation.
3. We supply the spare parts and technical support in and after the
warranty time.
4. We supply the training course to your workers at our factory if
you need.
5. We can offer site training to your workers in your place which
is negotiable.
C. After-sales service
1. Technical support for your installation, operation and
maintenance.
2. Standard warranty time: One years’warranty for heat pumps
You can also pay for extended warranty or we can renegotiate the
longer warranty period.
- Spare parts and technical support at most economic prices after the
warranty.
FAQ
Q1. Can I have a sample order for Heat pump or Water tank?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-10days, mass production time depend on the
products' quantity.
Q3.Do you offer guarantee for the products?
A: Yes, 12 months since the heat pump depart from the port of
loading (Refer to the Bill of Lading).
Certificate we have got :
1> ISO 9001, ISO 14000
2> Our company has been inspected and certificate by EMC
3> CE And EN14511, EN 14825-ERP for heat pump exported to Europe
4> Energy label for all heat pump models sold to over sea market
5> Testing laboratory calibrated by CNAS
Our leading products
Air to water heat pump, inverter heat pump, High water temperature
heat pump.
Mono block house heating heat pump, Split heat pump, Super low
noise heat pump
Heat pump dryer, Ground source heat pump, water to water heat pump,
swimming pool heat pump
MD50D Air source heat pump parameters tables
| MODEL | Unit | MD50D |
| Rated heating capacity | KW | 18 |
| Rated Cooling capacity | | 12 |
| Hot water supply | L/h | 400 |
| Average heating input power | KW | 4.4 |
| Rated heating input current | A | 9 |
| Max outlet water temp | C | 60 |
| COP | | 4.2 |
| Power | V/Hz | 380V/50 |
| Noise | Db(a) | 55 |
| Dimension | W*D*H | mm | 1120*490*1270 |
| Packing size | W*D*H | mm | 1200*520*1425 |
| Unit weight | KG | 160 |
| Refrigerant | | R417A/R407C/R404A |
| Working air temp range | | (-20℃)—45℃ |
| compressor | Type | | Copeland |
| Air source heat exchanger | Type | | Finned heat exchange |
| Fan Type | | axial flow fan |
| Hot water side heat exchange | Type | | Coil heat exchanger |
| Water flow | L/H | 5000L/h |
| Water pressure down | Kpa | 45 |
| Pipe size | DN | 25 |
| Max flat spuare meter | M2 | 150 |
