Ground source heat pump MDS300D-DY water circulation equipment can
refrigerate, warm and bathe.
Technology Specification
Heating capacity: 90KW
Cooling capacity: 63KW
Water production: 22000L/H
Input power: 21KW
Rated current: 40A
Rated water temperature: 55 ° C
Maximum water temperature: 60 ° C
Rated voltage: 380V/50HZ
Compressor: brand press
Working environment: (-40 ° C) - 45 ° C | Water source water flow: 60000L/H
Hot water end water flow: 25000L/H
Water source interface size: DN50mm
Hot water end interface size: DN50mm
Noise Db: ≤ 55Db
Evaporator: plate type, shell and tube heat exchanger
Condenser: casing heat exchanger
Throttle element: thermal expansion valve |
High-efficiency:
1) our own advanced heat pump technology
2) America Copeland Compressor
3) S & C high efficiency heat exchange
4) COP more than 4.4
5) saving cost as high as 60%~80% compared with oil boiler, gas boiler, coal boiler, electricity water heater etc.
Environment-friendly:
1) environment-friendly refrigerant: R417A/R407C/R410A/R404A/R134A
2) extract heat energy in the air and transfer it to heat water
through heat exchange
3) no potential hazards of inflammable, explosive, electric
shock,gas poisoning.
Our Services
1. After installation, our company will be responsible for problems
caused by quality of production or raw material except the
damageable spare parts of heat pump caused by incorrect man-made
operation during the guarantee period.
2. Intelligent Controlling service system will be avoid the long
distance of the after sale problem. Wherever are you, our engineer
can be controlled your equipment, when some questions occur on the
equipment. Just tell us what number will be shown on the screen,
then the engineer will be solve the problem.
3. We accept OEM, ODM and customization.
4. 24*7 after sales service. You will get satisfied service.
5. We have 19 years production and sales experience; Professional
sales team.
FAQ
- What details do you need?
- A: Water input and output temperature.
- B: Ambient temperature.
- Will it be too trouble to use water source water heater?
- Easy to use, once set, always have hot/cool water
- How long is the life of water source water heater
- Life time is 12-15 years
- How many years guarantee?
- 1 year
Our cooperate partner and Exhibition show
Packaging & Shipment
1> Meeting heat pump can sure delivery heat pump within 5~20
working days as we warehouse stock condition.
2> Heat pump with strong plywood pallet , strong plywood box for
loading, make sure no problem happen during rude transportation
3> All spare parts of the heat pump will together loading into
package , one time finished shipment to buyer.
4> Take video of the heat pump for buyer before package to 100%
sure buyer get product same as order, no any different.
5>Meeting heat pump offer 100% test online, 5% test in Lab by 24
hour for one lot order (if not new model)
Packaging Details :Standard export packing -with plywood case
packages,OEM is available for Factory price heat pump water heaters
Delivery Time :15 work days after arrival of down payment
