30KW Indoor Swimming Pool Heat Pump Air To Water Fresh Air And
Dehumidify
Technology Specification
| Rated voltage: 380V | Compression power: 5.2KW |
| Rated frequency: 50Hz | Fan power: 1.5KW |
| Rated current: 15A | Fresh air motor: 0.18KW |
| Rated pressure: 0.4Mpa | Total input power: 6.88KW |
| Rated water temperature: 28 ° C | Heating capacity: 30KW |
| Maximum water temperature: 38 ° C | Cooling capacity: 19KW |
| Water flow: 5000L/H | Dehumidification capacity: 20L/H |
| Interface size DN: 25 outer teeth mm | Blower voltage: 380V |
| Noise: 45Db | Air blower volume: 3080~6380m3 |
| Machine size (length * width * height): 2150 * 1050 * 1380mm | Blower full pressure: 552~605Pa |
| Package size (length * width * height): 2380 * 1280 * 1540mm | Fan static pressure: 539~555Pa |
| Air outlet size (length * width * height): 485 * 382mm | New fan voltage: 380V |
| Exhaust port size (length * width * height): 300 * 196mm | Fresh air volume: 800~1500m3 |
| New air outlet size (length * width * height): 300 * 196mm | New fan full pressure: 227~208Pa |
| Return air outlet size (length * width * height): 700 * 345mm | New fan static pressure: 217~176Pa |
| Evaporator: High-efficiency internally threaded tube is connected
with hydrophilic aluminum fins |
| Condenser: pure titanium tube heat exchanger or naval copper |
| Throttling element: thermal valve |
| External condenser: air-cooled (water-cooled can be customized) |
| Control system: with multiple parameter setting and query
functions, multiple fault protection and alarm functions |
Meeting High Efficent Energy Saving Three in One Air to Water
Swimming Pool Heat Pump Water Heater Constant Temperature and Big
Water Flowing
Functions:
- Dehumidification
- Constant temperature
- Initial temperature rise
- Fresh air
- Space heating & cooling
- Bathing
Packaging & Delivery
Packaging Details: export ply-wooden packing
Delivery Time: 15-30 days
Specifications
Swimming pool heat pump heating:
1. High efficiency & energy saving
2. Safe & Comfort
3. Convenient & widely to use
4. Swimming Pool Heat Pump heating:
- Swimming pool heat pump can save you up to 80% in operating cost
whether you just want to extend your swimming season or swim all
year round in a warm comfortable pool.
- With special designed heat exchangers, Swimming pool heat pump can
give you the perfect water temperature without a big increase in
your power bill, our swimming pool heat pump is a perfect selection
to your in-ground swimming pool or sea.
- The product can be widely installed at any kind of places, such as
constant temperature swimming pools, sauna constant hot water
system and supplying domestic hot water to home.
Swimming Pool Heat Pump heating:
* Long operating life
Using the advanced titanium in PVC or Nickel – copper in PVC shell
& tube heat exchangers, which can resist corrosion from chlorine in
the water.
* Economical and high efficiency
Using the more efficient heat pump technology, compared to other
ordinary hot water equipment (for example, combustion oil boiler,
comb-ussion gas boiler and electrical boiler),it reduces operation
cost by 65%~80%,moreover,it produces little pollution for
environment.
* Innovative design, easy installation and replacement.
Mono block (single unit conclusion) design, the unit is remarkable
compact and easy to install.
* Advanced control
It is extremely easy to control the swimming pump unit because of
the built-in computer with its intelligent control and LCD display.
* Use safely
Our Services
1. After installation, our company will be responsible for problems
caused by quality of production or raw material except the
damageable spare parts of heat pump caused by incorrect man-made
operation during the guarantee period.
2. Intelligent Controlling service system will be avoid the long
distance of the after sale problem. Wherever are you, our engineer
can be controlled your equipment, when some questions occur on the
equipment. Just tell us what number will be shown on the screen,
then the engineer will be solve the problem.
3. We accept OEM, ODM and customization.
4. 24*7 after sales service. You will get satisfied service.
5. We have 19 years production and sales experience; Professional
sales team.
- FAQ
- What is your advantage, comparing with other water heaters?
- A: Avoiding electric water heater leakage, dry, high power
consumption.
B: Avoiding the drawbacks of gas water heater, such as producing
harmful gases, Fits and starts etc.
C: Energy efficient, safety and environmental protection,
all-weather operation, easy to use.
- What details do you need?
A: Pool: Length, width, depth.
B: Ambient temperature.
C: Water input and output temperature.
- Will it be too trouble to use air water heater?
Easy to use, once set, always have hot/cool water
- How long is the life of air water heater
Life time is 12-15 years
- How many years guarantee?
1 year
