Meeting MDS150D 42KW Geothermal/Ground Source Heat Pump For Big
Space
Technology Specification
Quick Details:
| Heating capacity: 42KW | Water source side water flow: 15000L/H |
| Cooling capacity: 30KW | Hot water side water flow: 12000L/H |
| Rated voltage: 380V/50HZ | Water source side water pipe interface: DN32 |
| Rated current: 21A | Hot water side water pipe interface: DN32 |
| Input power: 11KW | Working environment: (-40°C) - 45 ° C |
| Rated water temperature: 55 °C | Evaporator: shell and tube heat exchanger |
| Maximum water temperature: 60 °C | Condenser: casing heat exchanger |
| Water production: 1200L/H | Throttle element: thermal valve |
| Noise Db: ≤ 55Db | |
| Machine size: 1050*810*760mm | Packing size: 1140*900*910mm |
| Remarks, Initial/final water temperature of load side :15℃/55℃,
Initial/outlet water temperature of source side, 15℃/ 10℃ |
Porduct feature:
1. Apply for imported compressor and famous accessories, reasonable
match makes unit performance perfect.
2. Apply unique dimensional structure design, smaller installation
size and no affect for indoor decoration appearance.
3. Unit can be used independently or in modular mode, each unit can
be independent charged for easy check computation.
4. Apply for advanced microcomputer control for easy understanding
for unit status.
5. High-efficient sound absorption &heating insulating material
and double layered vibration damped on design, it features
low-noise and bring enjoyment for security.
6. Each maintain, only to demount maintenance plate to repair, it
features modular design, other units still can normally operate
during maintenance.
A. Payment service
1. T/T
B. Technical service
1. We calculate the capacity and recommend the best models.
2.We supply you the professional refrigeration technical support
and electronic technical support for your installation, debugging
and operation.
3. We supply the spare parts and technical support in and after the
warranty time.
4. We supply the training course to your workers at our factory or
site training if you need.
C. After-sales service
1. Technical support for your installation, operation and
maintenance.
2. Standard warranty time: One years’warranty for heat pumps.
You can also pay for extended warranty or we can renegotiate the
longer warranty period.
3. Spare parts and technical support at most economic prices after
the warranty.
FAQ
Q1. Can I have a sample order for Heat pump or Water tank?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-10days, mass production time depend on the
products'quantity.
Q3.Do you offer guarantee for the products?
A: Yes, 12 months since the heat pump depart from the port of
loading (Refer to the Bill of Lading).
Certificsate we have got :
- ISO 9001, ISO 14000
- Our company has been inspected and certificate by EMC
- CE And EN14511, EN 14825-ERP for heat pump exported to europe
- Energy label for all heat pump models sold to oversea market
- Testing laboratory calibrated by CNAS
Use
Business Organizations, Supermarket, shopping malls, shops,
department store, star-rated hotels, restaurants, school, office;
Public Places, subway, airports, stations, bookstores, exhibition
halls, stadiums, museums, commercial buildings, hospital;
Entertainments Movie theaters, clubs, bars, cafes, Internet bars,
beauty shops
Packaging Details
Carton and Wooden Package,
Delivery Time
15 working days after get the deposit |
|
